Indoor LED Video Wall
High-definition indoor LED video walls with fine pixel pitch, vivid colors, and energy-efficient design—perfect for retail, offices, and control rooms.
Indoor 640×480 Fixed Hard Connection Series
Upgrade your space with JX Video Wall Pte Ltd’s Indoor 640×480 Fixed Hard Connection Series – engineered for precision, durability, and stunning visual performance.
✨ Key Features:
Multiple Pixel Pitch Options: 2mm, 2.5mm, 3.07mm, and 4mm – delivering crystal-clear resolution tailored to your needs.
Ultra-HD Visuals: High pixel density with seamless cabinet connection for sharp, vibrant displays.
Slim & Sturdy Design: Lightweight 8kg die-casting aluminum cabinet ensures durability and easy installation.
Wide Viewing Angle: 160° horizontal & vertical – perfect for immersive experiences.
High Brightness & Refresh Rate: ≥800 nits with up to 3840Hz refresh rate for flicker-free, camera-friendly visuals.
Energy Efficient: Average power consumption as low as 195W.
Long Lifespan: Built to last with >100,000 hours of operation.
📍 Ideal For: Corporate lobbies, retail stores, conference halls, control rooms, and studios.
Here’s a clean, brochure-ready technical specification table for your website. It consolidates the KP2, KP2.5, KP3.07, and KP4 models into one easy-to-read format:
Technical Specifications – Indoor 640×480 Fixed Hard Connection Series
Item | KP2 | KP2.5 | KP3.07 | KP4 |
Pixel Pitch | 2mm | 2.5mm | 3.076mm | 4mm |
Module Size | 320 × 160mm | 320 × 160mm | 320 × 160mm | 320 × 160mm |
Module Resolution | 160 × 80 | 128 × 64 | 104 × 52 | 80 × 40 |
Physical Density | 250,000 dots/m² | 160,000 dots/m² | 105,688 dots/m² | 62,500 dots/m² |
LED Type | SMD1515 | SMD2020 | SMD2020 | SMD2020 |
Cabinet Size | 640 × 480 × 59mm | 640 × 480 × 59mm | 640 × 480 × 59mm | 640 × 480 × 59mm |
Cabinet Resolution | 320 × 240 | 256 × 192 | 208 × 156 | 160 × 120 |
Cabinet Weight | 8kg | 8kg | 8kg | 8kg |
Cabinet Material | Die-Cast Aluminum | Die-Cast Aluminum | Die-Cast Aluminum | Die-Cast Aluminum |
Maintenance | Front | Front | Front | Front |
Best Viewing Distance | ≥2m | ≥2.5m | ≥3m | ≥4m |
Viewing Angle (H/V) | 160° / 160° | 160° / 160° | 160° / 160° | 160° / 160° |
Driving Method | 1/40 Scan | 1/32 Scan | 1/26 Scan | 1/20 Scan |
Video Frame Rate | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz |
Refresh Rate | 1920–3840Hz | 1920–3840Hz | 1920–3840Hz | 1920–3840Hz |
Brightness | ≥800 nits | ≥800 nits | ≥800 nits | ≥800 nits |
Grey Level | 12–16 bit | 12–16 bit | 12–16 bit | 12–16 bit |
Ingress Protection | IP43 | IP43 | IP43 | IP43 |
Avg. Power Consumption | 290W | 290W | 195W | 195W |
Life Time | >100,000 hrs | >100,000 hrs | >100,000 hrs | >100,000 hrs |
Failure Rate | <0.0002 | <0.0002 | <0.0002 | <0.0002 |
